Custom Block Plans
In addition to standard fire block plans, we produce custom block plans tailored to the specific layout, fire protection systems, and operational requirements of individual buildings.
These plans are commonly required for commercial buildings, industrial facilities, residential developments, hospitals, warehouses, and public infrastructure projects where specialised or non-standard fire protection documentation is needed.
Each block plan is produced as a precision aluminium acid etched paint filled techniques, providing high visibility, permanent markings, and long-term durability for building service areas and fire control rooms.
Getting your custom block plan produced is simple and efficient. Simply provide your block plan artwork/drawings in PDF format. Our team converts your drawings into a custom block plan layout, manufactures it using acid etched aluminium with paint filled block plans, and supplies your finished block plan ready for installation.
Available options:
ā¢ Materials: Aluminium (acid etched paint filled), Stainless Steel, or Polycarbonate
ā¢ Sizes: A1 (594 Ć 841 mm), A2 (420 Ć 594 mm), A3 (297 Ć 420 mm), A4 (210 Ć 297 mm) or any custom size
ā¢ Colours: As many as you want ā no artwork, preparation, or tooling costs
